Geological Groundwater
Assessments
Groundwater Evaluation for Construction and Development
Groundwater assessments in Sydney are essential to address risks such as basement flooding, soil liquefaction, slope instability, and environmental contamination. With rising urbanisation and climate-driven rainfall variability, understanding groundwater dynamics is critical for projects in flood-prone areas (e.g., Parramatta River catchment) or coastal zones where saltwater intrusion complicates water quality.
Key Assessment Objectives
Thorough evaluation of groundwater behavior ensures safe and sustainable construction.
-
Aquifer Characterisation
Mapping groundwater flow direction, velocity, and seasonal fluctuations.
-
Construction Impact Analysis
Predicting dewatering requirements for basements or tunnels.
-
Environmental Protection
Preventing contamination of aquifers used for drinking water (e.g., Botany Sands Aquifer).
Assessment Methodology
-
Hydrogeological Survey
- Installing piezometers or monitoring wells to measure water table depth and piezometric pressure.
- Conducting infiltration tests to determine aquifer hydraulic conductivity.
-
Water Quality Testing
- Analyzing pH, salinity, sulfates, and chlorides to assess corrosion risks to foundations (per AS 2159).
- Screening for contaminants (e.g., PFAS, hydrocarbons) in industrial zones.s.
-
Modelling
Using commercially available software to simulate groundwater flow and predict impacts of excavation or pumping.
Sydney-Specific Challenges
Coastal and low-lying areas in Sydney present unique groundwater challenges.
-
Tidal Influence
Coastal suburbs (e.g., Manly) experience tidal fluctuations in groundwater, complicating basement waterproofing.
-
Excavation Dewatering
High water tables in alluvial soils (e.g., Richmond) require cut-off walls or wellpoint systems to stabilise excavations.
-
Infrastructure Corrosion
Brackish groundwater in estuarine areas accelerates corrosion of steel piles and services.
Regulatory Compliance
Strict regulations govern groundwater management in Sydney.
-
NSW Aquifer Interference Policy
Requires licensing for large-scale groundwater extraction or dewatering.
-
Australian Standard AS 2870
Specifies foundation design requirements in sites with high water tables.
Mitigation Strategies
Effective groundwater management minimizes construction risks.
-
Dewatering Systems
Designing sumps, wellpoints, or exclusion barriers to lower groundwater during construction.
-
Waterproofing
Recommending basement types in high-risk zones.
-
Drainage Solutions
Drainage lines to divert groundwater away from foundations.
Reporting and Recommendations
A groundwater assessment report includes:
- Contour maps of water table elevations.
- Long-term monitoring plans for sensitive sites.
- Specifications for drainage, waterproofing, or corrosion protection.
